WallMax® rectangular holed flanged frame light openable (WRHFFLO)
WallMax® Rectangular Holed Flanged Frames Light Openable are alternative solutions to WRFFLO to be used where welding is not recommended.
WRHFFLO has a 6mm thick flange.
WRHFFLO frames can be assembled in a variety of combinations for what concerns both openings and construction materials.
Pre-defined solutions as well as customised options are offered to adjust to client’s needs.
WRHFFLO solutions are designed for installation where cables/pipes are already in place and it is not feasible to cut them and re-installed them.
They are supplied with a partially welded side. WRHFFLO are designed for installation through bolting or casting in the wall.
WRHFFLO frames are used in combination with WMR series and accessories to create personalised sealing solutions. Standard packing space allows for multiple combinations of WMR modules and a perfect fit to any customer’s need.
| Picture | SKU | Product name | Openings | Packing space (mm) | External nominal dimensions (HxW D=60mm) | Weight (kg) | Weight (lb) |
|---|---|---|---|---|---|---|---|
 |
* | WRHFFLO 60 1×1 Primed | 1×1 | 60×120 | 238×260 | 3.28 | 7.233 |
|
|
* | WRHFFLO 120 1×1 Primed | 1×1 | 120×120 | 298×260 | 3.95 | 8.710 |
|
|
* | WRHFFLO 180 1×1 Primed | 1×1 | 180×120 | 358×260 | 4.62 | 10.188 |
|
|
* | WRHFFLO 240 1×1 Primed | 1×1 | 240×120 | 418×260 | 5.30 | 11.687 |
|
|
* | WRHFFLO 60 1×1 AISI 316 | 1×1 | 60×120 | 238×260 | 3.36 | 7.410 |
|
|
* | WRHFFLO 120 1×1 AISI 316 | 1×1 | 120×120 | 298×260 | 4.05 | 8.931 |
|
|
* | WRHFFLO 180 1×1 AISI 316 | 1×1 | 180×120 | 358×260 | 4.70 | 10.364 |
|
|
* | WRHFFLO 240 1×1 AISI 316 | 1×1 | 240×120 | 418×260 | 5.45 | 12.015 |
|
|
* | WRHFFLO 60 1×1 Galv | 1×1 | 60×120 | 230×252 | 3.28 | 7.233 |
|
|
* | WRHFFLO 120 1×1 Galv | 1×1 | 120×120 | 290×252 | 3.95 | 8.710 |
|
|
* | WRHFFLO 180 1×1 Galv | 1×1 | 180×120 | 350×252 | 4.62 | 10.188 |
|
|
* | WRHFFLO 240 1×1 Galv | 1×1 | 240×120 | 418×260 | 5.30 | 11.687 |
* For the part number, please contact the Sales Department.
Note: weights are approx.
Key benefits:
- 6mm flange alternative to WRFFLO where welding isn’t suitable
- Openable frame with partially welded side
- Ideal for retrofits where cutting/re-installing cables and pipes is not feasible
- Designed for bolted or wall casting installation
- Supports a wide range of WMR module combinations
Materials
- Primed Steel
- SS AISI 316 L
- Galvanised Steel
Other materials available upon request.
